    Click-Torque X 7 torque wrench for insert tools, 10-100 Nm

    Release mechanism

    Release mechanism

    On reaching the desired torque value, an audible and tactile mechanism is triggered.
    For right and left direction

    For right and left direction

    The Click-Torque wrenches for insert tools are suitable forclockwise and counterclockwise uses.
    Click-Torque X 7 torque wrench for insert tools, 10-100 Nm
    • For 14x18 mm interchangeable insert tools
    • Easy setting and saving of the desired torque value with audible and tactile clicks when reaching the scale values
    • Audible and tactile release mechanism when the set torque value is reached
    • Measuring range: 10-100 Nm; precision ± 4 % as per DIN EN ISO 6789-1:2017-07
    • Very robust design with ergonomic 2-component handle suitable for right and left-handed use
    • The Click-Torque collar is placed around the tube of the Wera Click-Torque torque wrench. It prevents the handle from touching the ground. Dirt and damage are avoided. Also serves as "anti-roll protection".
    • The laser-engraved, abrasion-proof QR code makes it easier to determine the correct torque value depending on the torque wrench and insert tool used
    Click-Torque X 7 torque wrench with mounting for exchangeable insert tools 14x18 mm
    Simple and error-free determination of the torque value

    Simple and error-free determination of the torque value

    The laser-engraved, abrasion-proof QR code makes it easier to determine the correct torque value depending on the torque wrench and insert tool used. Simply scan with your smartphone or tablet (if available, both QR codes: torque wrench and insert tool). A website opens automatically which recognizes the scanned tools (no app needed!). Then enter the required torque value; the corrected value is determined automatically. No need to use formulas/calculations.
    Drive 14x18 mm

    Drive 14x18 mm

    For torque wrenches from the Click-Torque X series with 14x18 mm mounting.
    Exact

    Exact

    Precision of ±34 % as per DIN EN ISO 6789-1:2017-07.
    Easy and safe

    Easy and safe

    Easy setting and saving of the desired torque value; easy to read on main and fine scales.
    Setting with Speed

    Setting with Speed

    With audible and tactile locking when the scale values are reached.
    Release mechanism

    Release mechanism

    On reaching the desired torque value, an audible and tactile mechanism is triggered.
    For right and left direction

    For right and left direction

    The Click-Torque wrenches for insert tools are suitable forclockwise and counterclockwise uses.
    Click-Torque X 7 torque wrench for insert tools, 10-100 Nm
    • For 14x18 mm interchangeable insert tools
    • Easy setting and saving of the desired torque value with audible and tactile clicks when reaching the scale values
    • Audible and tactile release mechanism when the set torque value is reached
    • Measuring range: 10-100 Nm; precision ± 4 % as per DIN EN ISO 6789-1:2017-07
    • Very robust design with ergonomic 2-component handle suitable for right and left-handed use
    • The Click-Torque collar is placed around the tube of the Wera Click-Torque torque wrench. It prevents the handle from touching the ground. Dirt and damage are avoided. Also serves as "anti-roll protection".
    • The laser-engraved, abrasion-proof QR code makes it easier to determine the correct torque value depending on the torque wrench and insert tool used
    Click-Torque X 7 torque wrench with mounting for exchangeable insert tools 14x18 mm

    Article description

    Click-Torque wrench in the unmistakable, robust Wera design with high accuracy as per DIN EN ISO 6789-1: 2017-07. Easy setting and saving of the default value. The audible and tactile clicks on reaching the scale values also facilitate the safe setting of the desired torque value. The robust release mechanism guarantees a clearly audible and tactile release signal when the set torque is reached. For right and left-hand use and with square insert 14x18mm for insert tools.
    Click-Torque X 7 torque wrench for insert tools, 10-100 Nm
    Simple and error-free determination of the torque value
    Drive 14x18 mm
    Exact
    Easy and safe
    Setting with Speed
    Release mechanism
    For right and left direction
    Code Nm Nm lbf. ft. mm mm mm mm mm mm mm inch inch inch inch inch Nm Nm lbf. ft. lbf. ft.
    05075657001 1) 14x18 10-100 0.5 8-73 395 25.5 343.0 140 47 29 20 14 41/64" 5 33/64" 1 27/32" 1 9/64" 25/32" 10.0 100.0 8.0 73.0

    1) Sk = Actual dimension of the test attachment; lk = Distance from the force application point to the test device axis
