Click-Torque XP 3 pre-set adjustable torque wrench for insert tools, 15-100 Nm, 15 Nm

  • Torque
  • Pre-set

Article description

Torque wrench with pre-set torque value for all applications where the same torque and repeat accuracy is required. The torque value can be changed within the metered range. The robust release mechanism guarantees a clearly audible and tactile trigger signal when the set torque value is reached. Square socket for interchangeable plug-in tools for clockwise and anti-clockwise torque-control. A presetting which deviates from this value to a desired torque value within the specified metered range is possible on request.
Click-Torque XP 3 pre-set adjustable torque wrench for insert tools, 15-100 Nm, 15 Nm
Click-Torque XP 3 pre-set adjustable torque wrench for insert tools, 15-100 Nm, 15 Nm
Click-Torque Wrench series
Pre-set click torque wrenches
Drive 9x12 mm
Exact
Release mechanism
For right and left direction
Customised pre-setting
ar-view_view-in-ar-cookies-disabled

ar-view_view-in-ar-allow-ar-in-cookies

Code Nm Nm lbf. ft. mm mm mm mm mm mm mm inch inch inch inch inch Nm Nm lbf. ft. lbf. ft.
05075672001 1) 9x12 15.0 15-100 11-74 332 17.5 296.0 137 35 24 20 13 5/64" 5 25/64" 1 3/8" 15/16" 25/32" 15.0 100.0 11.0 74.0
05075672010 2) 1) 9x12 15.0 15-100 11-74 332 17.5 296.0 137 35 24 20 13 5/64" 5 25/64" 1 3/8" 15/16" 25/32" 15.0 100.0 11.0 74.0

1) Sk = Actual dimension of the test attachment; lk = Distance from the force application point to the test device axis

2) Any presetting which differs from this value, can be set to a desired torque value within the specified metered range upon request. The desired settings can be made in the following units: Nm, kgf. m, lbf. ft., ozf. in., dN. m, kgf. cm, lbf. in, in. oz, cN. m, gf. m, ft. lb, gf. cm, in. lb.
